Abrex 400 Plate, Abrex 500 Plate, Hardox 400 Plate, Hardox 500 Plate, SUMIHARD K500 Steel Plate, SUMIHARD K400 Steel Plate, DILLIDUR 400V Manufacturer & Exporter in India

We are one of the renowned manufacturer, exporter, stockist, stock holder and supplier of a qualitative range of Abrasion Resistant Plate that are being designed as per the national and international standard quality of raw materials. The key quality for abrasion resistant plate is their hardness. We offer wear plate as per its hardness measured on the Brinnell Hardness Test- for the most part in 400HB evaluations. Abrasion Resistant (AR) steel plate is typically made in the as-rolled condition. These types/grades of steel plate products have been developed specifically for long service life in harsh conditions.

Meanwhile, to meet the quality conscious requirements for our highly esteemed clients, we provide these Abrasion Resistant Plate in different sizes, grades and thickness as per customized requirements given by our customers.

Abrasion Resistant Plate Specification :

Specifications : ASTM, ASME and API
Width :1,500mm to 2,500mm
Thickness : 4.0mm - 100mm
Finish : Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Specialize : Shim Sheet, Perforated Sheet, B. Q. Profile.
Hardness : Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc.
Condition : Cold Drawn & Polished Cold Drawn, Centreless Ground & Polished
Type : Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.


Abrasion Resistant Plate Specification :

Specifications : ASTM, ASME and API

Width : 1,500mm to 2,500mm

Thickness : 5mm to 150mm

Length : 6,000mm to 12,000mm

Heat Treatment : N, Q+T

Surface Paint : EP, PE, HDP, SMP, PVDF

Material : ABREX 400 Plate, ABREX 500 Plate, Hardox 400 Plate, Hardox 500 Plate, SUMIHARD k500 Steel Plate, SUMIHARD k400 Steel Plate, DILLIDUR 400V Steel Plate , DILLIDUR 500V Steel Plate, Essar Rockstar 400 Abrasion Resistant Steel Plates, Essar Rockstar 500 Abrasion Resistant Steel Plates


Thickness Width Length
4 2000 6000
5 2000 6000
6 2000 6000
6 2500 6000
8 2000 6000
8 2500 6000
10 2000 6000
12 2000 6000
15 2000 6000
16 2000 6000
20 2000 6000
25 2000 6000
32 2000 6000
40 2000 6000
50 2000 6000
60 1800 3400

Chemical Properties :

Thickness mm Cut lengths 3 - 12 ---
Heavy Plates 5 - 30 (30) - 60
C 0.20 0.24
Si 0.70 0.70
Mn 1.70 1.70
P 0.030 0.030
S 0.015 0.015
Al 0.060 0.060
Cr 1.50 1.00
Ni 0.40 0.70
Mo 0.50 0.50
B 0.004 0.004

Mechanical Properties

Thickness mm Cut lengths Heavy Plates Yield strength Rp0,2 N/mm2 Tensile strength Rm N/m2 Elongation A5 % Hardness range HBW Impact strength t0C KV J
3 - 12 5 - 15 1000 1250 10 360 - 420 -40 40
-------- (15) - 30 1000 1250 10 380 - 450 -40 20
-------- (30) - 60 1100 1400 8 380 - 480 -40 20
